Features
- Capable of intercepting particulate matter, with a PM 1.0µm filtration precision of up to 99%. (Quantitative and weight results obtained with precision dust measuring instruments such as the GT-321/AEROCET-531)
- The filter cartridge is HEPA/F9 class and has been tested and approved by the TTRI. According to EN-799/2012, the filtration precision of particulate matter PM 0.4µm is above 95%.
- Large airflow volume, low noise, high performance.
- Optional new exclusive patented pressure difference gauge capable of indicting front-end and back-end filter blockages.
- Patent number M467835/M436140/D144057/D161095
Specification
| Model | Unit | LOMA-10H | LOMA-15H | LOMA-20H |
|---|---|---|---|---|
| Motor | KW | 0.18 | 0.37 | 0.56 |
| Load Current | A | 2.3 / 1.4 | 2.8 / 1.7 | 3.2 / 1.9 |
| Voltage | V/HZ | 3ø 220V / 380V / 60Hz / 50Hz | ||
| Air Flow | m3/min | 15 / 12 | 20 / 16 | 25 / 20 |
| Noise Level | db | 65 / 63 | 66 / 64 | 67 / 64 |
| Intake Port Dia | mm | ø148 | ø148 | ø148 |
| Dimensions | mm(LxWxH) | 660x350x749 | 675x350x780 | 780x390x839 |
| Weight | kg | 36.4 | 39.6 | 45.8 |
